Specifications & Reference

Not very exciting I know, but with any renovation project there seems to be an endless amount of records that should be in good order. I've been lucky so far in that I've kept various bits of paper stashed here and there, or saved old e-mails and electronic invoices to keep track of things. One of the points of this web site is to maintain an archive of photos and information that won't get lost, so here's the part with the various specifications I don't want to lose.

The sections include The Color Palette, which contains all the various color codes for paints, stains, and other finish surfaces used in the project. I've created a Project Timeline section that attempts to show all the various renovation projects in the order they occurred, although the earliest stuff is a little fuzzy. The Power Tool Data section contains model and serial numbers for tools used in the renovation as well as outdoor power equipment (automotive tools may get added after we have a garage and I get them out of storage).

This page contain some general information about the house, and I'll likely add some specifics for fixtures, appliances, etc. (basically anything with an owner's manual that might require service at some point). I also intend to archive complete sets of plans I have locally, as well as some supplier information, even though I'm not a big fan of trying to maintain external links (since that's what bookmarks are for, after all). There's also a Reference Materials section that lists the general reference and how-to books that don't fit in other specific sections of the site.


General House Information


Property Type: Single Family, Single Story Heating System: Hydronic Radiant Floor
Square Footage: 912 Cooling System: Single-Zone Ductless Mini-Split
Bedrooms: 1 Insulation: R16.8 (floor); R13 (walls); R49 (attic)
Bathrooms: 1 Roof: Laminated Fiberglass / Asphalt Composite
Basement: Crawl Space Windows: Fiberglass-clad Wood, Low-E II dbl-pane
Lot Size: 10,158 sq ft / 0.23 acres Electrical Service: 200a, 220v single-phase, underground
Year Built: 1952 Water Service: Municipal & Deep Well (irrigation only)
Purchased: June 10, 2002 Sewer Service: Septic Tank(s) w/ Pump-up Leach Field

House Plans

House Plans
These plans contain multiple revisions, showing the various changes adopted as work progressed. There are also some detail sheets for certain projects within the scope of the main plan set. Most of these plans are also available in their appropriate sections of the Kesterhouse.com site.

The PDF versions are for reference use, and will remain clear regardless of zoom level (and the files are quite small). Each document will open in a new window.
PDF Exterior Plans (20 pages)
PDF Floor Plans (5 pages)
PDF Attic Hatch Plans (9 pages)
PDF Bedroom/Closet Plans (10 pages)
PDF Living Room Ceiling Plans (10 pages)
PDF Tokonoma Plans (1 page)
PDF Teahouse Plans (19 pages)
PDF Deck Plans (5 pages)
PDF Garage Plans (9 pages)

Major Household Appliances
Kitchen appliances are from KitchenAid, with the laundry appliances from Frigidaire.

 Description  Model  Serial No.  Notes  Mfg. Dt.
Frigidaire® Gallery Supreme Electric Clothes Dryer PDF GSEQ642AS1 XC24507405 10/02
Frigidaire® Gallery Supreme Front-load Washer PDF GSTF1670AS0 XC24706607 11/02 Energy Star
KitchenAid® Architect® Series Double-drawer Dishwasher PDF KUDD01DPPA1 FPT3015704 10/05 Energy Star
KitchenAid® Architect® Series Freestanding Convection Gas Range PDF KGSA906PSS02 XT1814922 10/05
KitchenAid® Architect® Series Microwave/Hood Combination PDF KHMS155LSS3 TRS4039339 10/05 1.5 cu.ft., 1,000w
KitchenAid® Architect® Series Top-freezer Refrigerator PDF KTRA22EMSS03 ES4416354 10/05 21.5 cu.ft. Energy Star


Window & Door Thermal Performance Data

All windows and doors are Integrity® Ultrex-Wood Clad units, with the exception of the round window, which is a Marvin® Aluminum-Wood Clad direct glaze unit. All units comply with ANSI/AAMA/WDMA/101/I.S.2.97, ANSI/101/1.S.2/NAFS-02, and AAMA/WDMA/CSA 101/1.S.2/490-05 C-LC50, AP-LC50, and FW-LC50.

The table of Certified National Fenestration Rating Council (NFRC) unit values below contains the following: U-Value: (Btu/hr-sq ft-°F) The lower the U-Value, the greater the resistance to heat flow and better its insulating value. R-Value: (1/U-value) The higher the R-value, the greater the resistance to heat flow and better its insulating value. Visible Light Transmittance (VLT): The percentage of visible light transmitted through the glass. Solar Heat Gain Coefficient (SHGC): The lower the number, the less solar heat it transmits, and the greater its shading ability. Condensation Resistance (CR): Condensation Resistance measures the ability of a product to resist the formation of condensation on the interior surface of a product. The higher the CR rating, the better that product is at resisting condensation formation.

All units are Energy Star (Northern) certified. Energy Star

 Description  Model  NFRC Glazing Type  U-Value  R-Value  SHGC  VLT  CR
Integrity Inswing French Door PDF IIFD6068 XXR Low E II Argon 0.30 3.33 0.27 0.47 60
Integrity Sliding French Door PDF ISFD6068 XO Low E II Argon 0.31 3.23 0.30 0.49 60
Integrity Casement Window PDF ICA2539 3W Low E II Argon 0.31 3.23 0.30 0.50 58
Integrity Casement Window (2) “ ”  ICA2539 Low E II Argon 0.31 3.23 0.30 0.50 58
Integrity Glider Window (2) PDF IGL4860 Low E II Argon 0.30 3.33 0.31 0.54 57
Integrity Glider Window (6) “ ”  IGL4842 Low E II Argon 0.30 3.33 0.31 0.54 57
Marvin Direct-glazed Fixed Full Circle PDF CFCIR3950 Low E II Argon 0.30 3.33 0.27 0.47 58


Mechanical Systems Data

Updated Wiring Plans
These are the latest revisions of the wiring plans and service panel layout. I've also included a couple of detail sheets with the wiring for all the 3-way light switch circuits, which tend to make my head explode if I don't have something on paper when trying to connect those darn things together properly.

Wiring Plans
The PDF versions are for reference use, and will remain clear regardless of zoom level (and the files are quite small). I haven't updated the service panel layout data in a while, so most of the lighting circuit loads listed are for the old incandescent fixtures, rather than the new LEDs with which almost everything has been replaced. I'll get to it eventually. I did do through the 30-page wiring plans, and get all those up to date with the most recent work (2023) in the attic and laundry room. Each document will open in a new window.
PDF Service Panel Layout (2 pages)
PDF Individual Circuit Wiring Plans (30 pages)
PDF 3-way Light Switch Wiring Plans (4 pages)

Electrical Service Equipment
The following table contains data and cut sheets for the service panel and circuit breakers, as well as the interlock kit to isolate utility line input from the panel while running on standby power in the event of a power outage. All load center equipment is made by Siemens Energy / Murray Electrical Products.

 Description  UL Type  Catalog No.  Notes
Murray® Indoor Load Center PDF 1 LC4040B1200*
Murray® Main Bolt-in Circuit Breaker PDF M2 MBK225M 2-pole 200a
Murray® Branch Plug-in AFCI Circuit Breaker PDF MP-AT MP120AF 1-pole 20a Arc-Fault Circuit Interrupter
Murray® Branch Plug-in GFCI Circuit Breaker PDF MP-GT MP120GF 1-pole 20a Ground-Fault Circuit Interrupter
Murray® Branch Plug-in Circuit Breaker PDF MP-T MP115, MP120, MP220, MP230 1-pole 15a, 20a; 2-pole 20a, 30a
Siemens® Interlock Kit PDF -- ECSBPK03 standby power manual transfer
Square D® A/C Disconnect Switch PDF -- QO200TR NEMA 3R enclosure
Square D® 30A Gen. Duty Safety Switch PDF 3130 D.221.N NEMA 1, well pump switch
UL Class Rk5 15A Time-delay Cartridge Fuses (2) FRN-R/ TR-R/ FLN-R well pump switch fuses

Standby Power Equipment
In addition to the Siemen's Interlock Kit installed in the main service panel, the items below are utilized to supply standby power when the utility power is unavailable.

 Description  Model  Serial  Notes
Generac® GP8000E Portable Generator PDF 5696-0 5563654 8,000w (10,000w surge), gasoline, electric start
Reliance Controls Power Inlet Box PDF PB30 -- NEMA L14-30R male plug, 30a, NEMA 3R enclosure w/ cover
Reliance Controls PowerBACK™ PDF THP108 -- 100dB utility power return alert, 9V battery
Ridgid Tools Generator Cord 615-18046AB -- NEMA L14-30R plugs, 25' 10/4 outdoor cord

Light Fixtures & Lamps
The following table contains information regarding light fixtures and replacement lamp specifications for lighting used throughout the house. Buying a replacement bulb used to be a lot less complicated...

 Description  Model  Lamp  Notes
"Affordable Quality" Louvered Recessed Step Light PRLB-HS 120VAC, 3w, 3,000K LED, GY-6.35 Bi-Pin base Genkan floor fixtures
Fantech® ICAT Ceiling Grill / Light Housing PDF PBF4 11w, 2,700K, R30 LED, GX24q 4-pin base Bathroom shower fixture Energy Star
GE® 24" Advantage 3-Light Under-cabinet PDF 10163 120VAC, T-4 JCD 3w, 3,000K LED, G-8 Bi-Pin base Kitchen, hardwired
Generic, 4-foot, Two-light, Fluorescent "Shop Lights" -- 18w, T-8 Type B, single-ended LEDs Attic & Garden Shed fixtures
Halo® 4" AIR-TITE™ Recessed PDF H99ICT GE® #93360 7w, 2,700K, PAR20 LED, E26 base #953SN baffle trim (kitchen)
Halo® 4" AIR-TITE™ Recessed “ ”  H99ICT Sylvania #40930 6w, 3,000K, PAR16 LED, E26 base Gimbal trim (bedroom & toko)
Halo® 4" LED Recessed Retrofit Module PDF LT460WH6950 7.9w, 5,000K, 90CRI integral LED Engawa ceiling fixtures
Halo® 6" H7 AIR-TITE™ Recessed PDF H7ICAT Sunco® 11w, 2,700K, PAR30 LED, E26 base #310W baffle trim (living room)
Halo® 6" H7 AIR-TITE™ Recessed “ ”  H7ICAT TCP® 9.5w, 2,700K, BR30 LED, E26 base #310SN baffle trim (bathroom)
Ikea® "Dioder" In Cabinet Fixtures PDF -- 8w, 12v LED Kitchen cabinets
Ikea® "Hemma" Lamp Base PDF -- TCP® A19/G25 5w, 2,700K LED, E26 base Genkan hanging fixtures
Kuzco® "Bedford" Ceiling Flush Mount PDF FM3506-BN 120VAC, 7w, 3,000K LED, G-9 Looped Bi-Pin base Closet/Laundry room fixture
Lithonia® 24" Square-Basket Wraparound PDF SB 2 17 9w, T-8 Type B, single-ended LEDs Utility room fixture
Lithonia® BNP Disk Ceiling Flush Mount PDF 11560 33w, 9.84" LEDY Type C, magnetic-mount LED Kitchen fixture Energy Star
Lithonia® HGX Security Flood PDF 2RH 40K 120 DDB 120VAC, 25w, 4,000K LED Outbuilding flood lights Energy Star
Malibu Lighting® Round Deck Light PDF LT8K 12VAC, .85w 3,000K LED, T10/194 Wedge base Engawa post fixtures
Maxim® "Cilandro" 1-Light Wall Sconce PDF 53006WTSN TCP® B11, 5w, 2,700K LED, E12 base Bathroom mirror fixtures
Moonrays® Outdoor Lighting Transformer PDF 95341 120w 12VAC Power Supply Replacement for YardBright unit
Progress Lighting "Inspire" 2-Light Flush Mount PDF P3713-20 Sylvania #40806 8w, 2,700K, A19 Clear LED, E26 base Bedroom fixture
Quoizel® "Hillcrest" Small Wall Lantern PDF HC8406IB TCP® A-15, 5w Cold Cathode CCFL, E26 base Front porch fixtures
RAB® Outdoor Bullet Flood PDF QB1A 75w T-4 Halogen, G-8 Bi-Pin base Perimeter flood lights
RAB® Outdoor Bullet Flood PDF QB1A 120VAC, T-4 JCD 3w, 3,000K LED, G-8 Bi-Pin base Perimeter down lights
SUNVIE® Shielded In-ground Well Lights B09B73XK68 12VAC, 12w, 3,000K LED fixture Bamboo perimeter uplights
UltraPro 18" Under-Cabinet Light PDF 45367 120VAC, 9w, 3,000K (selectable) strip LED Laundry, hardwired
YardBright® Louvered Brick Light GBT5030 12VAC, 20w JCD Halogen, G-5.3 Bi-Pin base Tsukimi-dai step fixtures
YardBright® Tulip Hanging Light GBT5021H 12VAC, 3w LED, G-4 Bi-Pin base Narabe tsuru (socket only)

Receptacles, Switches & Wall Plates
Receptacles and their wall plates are from Cooper® Wiring Devices. All lighting controls and their wall plates are from the Lutron® Designer series, with the exception of the black light switches (for the kitchen backsplash) which are also from Cooper® Wiring Devices, and the occupancy sensor from Leviton®.

 Description  Model  Color  Notes
Cooper® Commercial Straight Blade Single Receptacle PDF 1877A Almond NEMA 5-20R, 20A
Cooper® Commercial Straight Blade Duplex Receptacle “ ”  CR15A Almond NEMA 5-15R, 15A
Cooper® Commercial Straight Blade Duplex Receptacle “ ”  CR20A Almond NEMA 5-20R, 20A
Cooper® Decorator Comm. Straight Blade Duplex Receptacle “ ”  6352B Black NEMA 5-20R, 20A
Cooper® Decorator Comm. Single-pole & 3-way Switches PDF 7601B & 7603B Black 15A (kitchen only)
Cooper® Mid-size 1-gang Single Receptacle Wall Plate PDF 2031A Almond Thermoset
Cooper® Mid-size 1-gang Duplex Receptacle Wall Plate “ ”  PJ8A Almond Polycarbonate
Cooper® Mid-size 2-gang Duplex Receptacle Wall Plate “ ”  PJ82A Almond Polycarbonate
Leviton® Occupancy Sensor PDF PR150-1LA Almond Genkan floor lighting
Lutron® Caséta® SmartBridge™ PRO PDF L-BDGPRO2-WH White
Lutron® Caséta® Smart Light Switch PDF PD-6ANS-LA Light Almond
Lutron® Caséta® Smart Dimmer Switch PDF PD-6WCL-BL Black Kitchen 4" task lights
Lutron® Caséta® Smart Dimmer Switch “ ”  PD-6WCL-LA Light Almond
Lutron® Caséta® Smart PRO Dimmer Switch PDF PD-10NXD-LA Light Almond Outside perimeter downlights
Lutron® Caséta® Smart Fan Speed Control Switch PDF PD-FSQN-LA Light Almond
Lutron® Caséta® Weatherproof+ Outdoor Smart Plug On/Off Switch PDF PD-15OUT-BL Black
Lutron® Pico Wireless Dimmer Control w/Nightlight PDF PJN-3BRL-GLA-L01 Light Almond w/ CR2032 battery
Lutron® Pico Wireless Dimmer Control “ ”  PJ2-3BRL-GLA-L01 Light Almond w/ CR2032 battery
Lutron® Pico Wireless Light Control “ ”  PJ2-2B-GLA-L01 Light Almond w/ CR2032 battery
Lutron® Pico Wallplate Adapter PDF PICO-WBX-ADAPT --
Lutron® Minimum Load Capacitor PDF LUT-MLC -- For closet LED fixture
Lutron® Claro® Single-pole Switch PDF CA-1PSH Almond (gloss finish)
Lutron® Claro® 3-way Switch PDF CA-3PSH Almond (gloss finish)
Lutron® Diva® SP Preset Incandescent/Halogen Dimmer PDF DV-600P Almond (gloss finish) 600 watt w/ Locator Light
Lutron® Claro® Screwless Wallplate PDF CW-1, 2, 3 & 4 Almond (gloss finish) 1, 2, 3, & 4 gang plates
Lutron® Claro® Screwless Wallplate “ ”  CW-2 SS Stainless Steel 2 gang (kitchen only)

Plumbing Equipment
The following table includes filtration, irrigation, pond pumps, septic system, and water supply equipment.

 Description  Model  Serial No.  Notes
Alita® Linear Air Pump PDF AL-40 -- 1.4 CFM / 40 LPM
CMS Magnetics Water Treatment Magnets (3) PDF WTS-100 -- Installed on well, hot & main
Franklin Electric® Submersible Water Well Pump PDF 214 503 90--S -- 1/3hp, 3-wire
Franklin Electric® 1/3hp Submersible Well Pump Control PDF 280 103 4915 -- Type Q, 1P 230v
Hydromatic® Submersible Sewage Ejector Pump PDF SP40 --
Legend Valve® Quarter-Turn T-550 Frostfree Sillcock (3) PDF 108-153 -- 8" w/ vacuum breaker
Oatey® Quadtro® Washing Machine Outlet Box PDF 38542 -- 1/4 turn hammer ball valve, crimp connectors
Orbit® 6-Station "Easy-Dial" Irrigation Timer PDF 57856 -- PDF w/ #57069 Rain/Freeze Sensor
Orbit® WaterMaster Auto Inline Irrigation Valve (4) PDF 57100 -- 3/4"FPT, without flow control
Pentek® 20" Big Blue® Filter Housing PDF 150233 -- 1" FPT w/ WB-SS mounting kit
Pentek® 10" Big Blue® Filter Housing “ ”  150237 -- 1" FPT
Pentek® EPM Series Filter Cartridge PDF EPM-20BB -- municipal water filter
Pentek® NCP Series Filter Cartridge PDF NCP-BB -- well water filter
PÜR/Whirlpool®/KitchenAid® Quarter-turn Ice/Water Filter PDF 4396701 -- refrigerator grill
Square D® Pumptrol™ Pressure Switch PDF 9013FSG 2J21 -- 30 / 50 psi
ShinMaywa® Norus® CR Pond Pump PDF 50CR2.25S -- 1/3 HP unit
SJE-Rhombus® Type 112 Single Phase Simplex Pump Control PDF 1121W110H -- NEMA 4x enclosure
Watts® Closed End x 1" Swedged End Manifolds (2) PDF WPCM1-M8-08B -- 8 Branch x 1/2" CF/MBV
Watts® Ice Maker Valve and Enclosure PDF WPIME-1 -- 1/2 turn PEX valve
Watts® Reduced Pressure Zone Backflow Preventer PDF 1-009M2-QT 136223 1" FPT
WellMate™ WM-6 19.8 gal Captive Air Tank PDF WM0075 16507-558 1" MPT

Plumbing Fixtures
Kitchen plumbing fixtures are from Delta and Danze with an Elkay stainless-steel sink. Bathroom fixtures are from Brizo, with a Toto toilet and sink, and the shower from Maax.

 Description  Model  Color  Notes
Broan® Metro Oversized Frameless Medicine Cabinet PDF 52WH304DPF -- 24"w x 5"d x 30"h, flat mirror
Brizo® Euro Collection Sensori™ Body Spray (2) PDF T84101-BN Brushed Nickel H20kinetic Technology®
Brizo® Euro Collection Diverter Valve & Trim PDF T60620-BN Brushed Nickel Rough valve #R60600
Brizo® Euro Collection Raincan Showerhead PDF RP44103-BN Brushed Nickel w/ #RP48985BN ceiling mount
Brizo® Euro Collection "Tempassure" Valve & Trim PDF T60220-BN Brushed Nickel Rough valve #R600000-UNBX
Brizo® Euro Collection Shower Slide Bar w/ Handheld Shower PDF 85521-BN Brushed Nickel Quiessence® series
Brizo® Single-hole Lavatory Faucet PDF 651452-BN Brushed Nickel Quiessence® series
Danze® Parma™ Single-handle Pot Filler PDF D205358-SS Stainless Steel Wall-mount
Delta® Grail® Single-handle Pull-down Kitchen Faucet PDF 985LF-SS Brilliance® Stainless Single-hole
Elkay® Elumina™ Top-mount Single-bowl 18ga. Sink PDF EG25220 Stainless Steel 8-1/4" bowl depth
Elkay® Basket Strainer with Tailpiece PDF LKKDT35 Stainless Steel 3-1/2" strainer
Maax®-Aker® 1-piece Shower PDF ACSH-RD 001 White 35-1/4" x 36-1/4"
Maax®-Aker® Tulley® 1-panel Shower Door PDF 137595 105 Nickel Clear tempered glass doors
Toto® Nexus® Vessel Lavatory PDF LT791 01 Cotton Single-hole
Toto® Nexus® Close-coupled Toilet PDF CST794SF 01 Cotton G-Max® 1.6GPF, ADA height
Toto® Washlet® S300 Toilet Seat PDF SW554 01 Cotton Elongated
Warmrails® Towel Warmer PDF Towel Shelf Satin Nickel Hard-wired

HVAC Equipment
Domestic hot water and the heat plant are from Heat Transfer Products. Ventilation products are from Fantech. Air-conditioning equipment is from Mitsubishi.

 Description  Model  Serial No.  Notes
Bell & Gossett Hydrotrol® Valve PDF HT-1 -- 1" Indirect check-vlave
Fantech® Heat Recovery Ventilator w/ Defrost Recirculation PDF VHR 1405R 12990015 L type KAV0140 Energy Star
Fantech® Intellitek 5MR Multifunction HRV Control PDF EDF5 --
Fantech® 15-minute HRV Override Control PDF RTS2 --
Fantech® Premium Bath Fan w/ Fluorescent Light PDF PB 100F -- 100cfm, 4" duct Energy Star
Fantech® Electronic Timer Control PDF FD 60EM -- (Leviton® LTT601L)
Heat Transfer Products Munchkin™ Boiler PDF T80M G21L12682 w/ Concentric Vent kit Energy Star
Heat Transfer Products SuperStor® Indirect Fired Water Heater PDF SS-40 IO6G 46268L 40 gal.
Heat Transfer Products Vision 1® Advanced Boiler Control System PDF -- --
Honeywell® Wi-Fi 7-day Programmable Thermostat PDF RTH6580WF1001/U1 --
Mitsubishi® Mr. Slim® M-Series Ductless Mini-Split A/C w/Heat Pump PDF MUZ-GE15NA -- Outdoor Unit Energy Star
Mitsubishi® Mr. Slim® M-Series Ductless Mini-Split A/C w/Heat Pump PDF MSZ-A15NA-1 -- Indoor Unit Energy Star
Spirotherm® Spirovent® Jr. Microbubble™ Air Eliminator PDF VJR-100TM -- 1" FPT
Taco® Viridian® ECM High-Efficiency Circulator PDF VR1816-HY1-PUR2 -- Zone Circulator pump
Taco® "00e"® ECM High-Efficiency Circulator PDF 007e-2F4 -- Call for Heat (P1) pump
Taco® "00"® Cartridge Circulator PDF 0010-F3-IFC -- Indirect (P2) pump
Taco® Single Zone Switching Relay PDF SR501 -- for P1 pump
Watts® Boiler Feed-water Pressure Regulator PDF B1156F 0508W 10-25 psi
Watts® Dual Check Backflow Preventer w/Vent PDF 9D-M3 0504C 1/2"
Watts® Pressurized Expansion Tank PDF ET-30 -- EDP #067411




Reference Materials

When I need to figure out how to do something on the house, these are the construction reference and project idea books I look to for answers:

Shoji: How to Design, Build, and Install Japanese Screens

Shoji: How to Design, Build, and Install Japanese Screens
by Jay Van Arsdale
Publisher: Kodansha International
Pub. Date: July 1997
ISBN-13: 978-0870118647




Making Shoji



Making Shoji
by Toshio Odate, Laure Olender
Publisher: Linden
Pub. Date: March 2000
ISBN-13: 978-0941936477

Japanese Cabinetry

Japanese Cabinetry: The Art & Craft of Tansu
by David Jackson, Dane Owen
Publisher: Gibbs Smith, Publisher
Pub. Date: 2002
ISBN-13: 978-1586851132





Traditional Japanese Furniture



Traditional Japanese Furniture: A Definitive Guide
by Kazuko Koizumi
Publisher: Kodansha International
Pub. Date: September 1995
ISBN-13: 978-0870117220

Tansu: Traditional Japanese Cabinetry

Tansu: Traditional Japanese Cabinetry
by Ty Heineken
Publisher: Weatherhill
Pub. Date: November, 2004
ISBN-13: 978-0834805484




The Japanese Bath



The Japanese Bath
by Bruce Smith, Yoshiko Yamamoto
Publisher: Gibbs Smith, Publisher
Pub. Date: April, 2001
ISBN-13: 978-1586850272

Making Japanese-Style Lamps and Lanterns

Making Japanese-Style Lamps and Lanterns
by Edward R. Turner
Publisher: Hartley & Marks, Incorporated
Pub. Date: December, 2002
ISBN-13: 978-0881791983




Wood Finishing 101



Wood Finishing 101: The Step-by-Step Guide
by Bob Flexner
Publisher: Popular Woodworking Books
Pub. Date: June, 2011
ISBN-13: 978-1440308451

Lettering & Sign Carving

Lettering & Sign Carving Workbook
by Betty Padden
Publisher: Fox Chapel Publishing
Pub. Date: March, 2011
ISBN-13: 978-1565234529




Letter Carving in Wood


Letter Carving in Wood
by Chris Pye
Publisher: Guild of Master Craftsman Publications
Pub. Date: October, 2007
ISBN-13: 978-1565232105

The Essential Woodworker

The Essential Woodworker  ca. 1988
by Robert Wearing, Christopher Schwarz (Editor)
Publisher: Lost Art Press
Pub. Date: Revised Edition, 2010
ISBN-13: 978-0578060446




The Joiner and the Cabinet Maker   The Joiner and the Cabinet Maker

The Joiner and the Cabinet Maker  ca. 1839
by Anonymous
Commentary: Joel Moskowitz & Christopher Schwarz (signed)
Publisher: Lost Art Press
Pub. Date: January, 2009, ISBN-13: 978-0578039268
The Joiner and the Cabinet Maker  (non-commented historical reprint)
Reprint Pub. Date: 2019, ISBN-13: 978-1732210097

Anarchist's Design Book

The Anarchist's Design Book
by Christopher Schwarz (signed)
Publisher: Lost Art Press
Pub. Date: March, 2016
ISBN-13: 978-0990623076




Campaign Furniture


Campaign Furniture
by Christopher Schwarz (signed)
Publisher: Lost Art Press
Pub. Date: 2014
ISBN-13: 978-0985077792

Mouldings in Practice

Mouldings in Practice
by Matthew Sheldon Bickford
Publisher: Lost Art Press
Pub. Date: 2012
ISBN-13: 978-0985077716




Mechanics Exercises


Mechanick Exercifes
or the Doctrine of Handy-Works
  ca. 1703
by Joseph Moxon
Publisher: Lost Art Press
Pub. Date: 2022
ISBN-13: 978-1954697072

Mechanic's Companion

Mechanic's Companion  ca. 1812
by Peter Nicholson
Publisher: Lost Art Press
Pub. Date: 2021
ISBN-13: 978-1954697010




Woodwork Joints


Woodwork Joints  ca. 1920
by William Fairham
Publisher: Toolemera Press
Pub. Date: 2010
ISBN-13: 978-0982532973

Woodwork Joints

Woodwork Joints  ca. 1950
by Charles H. Hayward
Publisher: Evans Brothers Ltd.
Pub. Date: 1960
ASIN: B000SFC1C2




Woodworker's Pocket Book

Woodworker's Pocket Book  ca. 1949
Edited by Charles H. Hayward
Publisher: Lost Art Press
Pub. Date: 2021
ISBN-13: 978-1733391696



The Woodworker


The Woodworker — The Charles Hayward Years 1939-1967
Vol. I: Tools, Vol. II: Techniques, Vol III: Joinery, Vol. IV: The Shop & Furniture
by Charles H. Hayward
Compiled by Christopher Schwarz
Publisher: Lost Art Press
Vol. I & II Pub. Date: 2016, ISBN-13: 978-0990623083
Vol. III Pub. Date: 2016, ISBN-13: 978-0997870213
Vol. IV Pub. Date: 2017, ISBN-13: 978-0997870220

Honest Labor

Honest Labor: The Charles Hayward Years, 1936-1966
edited by Kara Gebhart Uhl
Publisher: Lost Art Press
Pub. Date: 2020
ISBN-13: 978-1733391634





The Book of Plates


l'Art du Mensuisier  (The Art of the Joiner)
The Book of Plates  ca. 1769-1774
by André-Jacob Roubo
Translation & Commentary: Donald C. Williams, Christopher Schwarz
Publisher: Lost Art Press
Pub. Date: October, 2014
ISBN-13: 978-09905623014

To Make as Perfectly as Possible

l'Art du Mensuisier  (The Art of the Joiner), vol. I
To Make as Perfectly as Possible: Roubo on Marquetry  ca. 1769-1774
by André-Jacob Roubo
Translation & Commentary: Donald C. Williams, Michele Pietryka-Pagán, Philippe Lafargue
Publisher: Lost Art Press
Pub. Date: October, 2013
ISBN-13: 978-0985077754






With All the Precision Possible


l'Art du Mensuisier  (The Art of the Joiner), vol. II
With All the Precision Possible: Roubo on Furniture  ca. 1769-1774
by André-Jacob Roubo
Translation & Commentary: Donald C. Williams, Michele Pietryka-Pagán, Philippe Lafargue
Publisher: Lost Art Press
Pub. Date: March, 2017
ISBN-13: 978-0997870237

New Bathroom Idea Book

New Bathroom Idea Book
by Andrew Wormer
Publisher: Taunton Press
Pub. Date: October, 2005
ISBN-10: 1561586927




All New Kitchen Idea Book



All New Kitchen Idea Book
by Joanne Kellar Bouknight
Publisher: Taunton Press
Pub. Date: Revised edition, January, 2009
ISBN-13: 978-1600850608

Insulate and Weatherize

Insulate and Weatherize: Expert Advice from Start to Finish
by Bruce Harley
Publisher: Taunton Press
Pub. Date: October, 2002
ISBN-13: 978-1561585540




Graphic Guide to Interior Details



Graphic Guide to Interior Details: For Builders and Designers
by Rob Thallon
Publisher: Taunton Press
Pub. Date: October, 1998
ISBN-13: 978-1561583249

Graphic Guide to Frame Construction

Graphic Guide to Frame Construction: Details for Builders and Designers
by Rob Thallon
Publisher: Taunton Press
Pub. Date: October, 2000
ISBN-13: 978-1561583539




Wiring Simplified



Wiring Simplified: Based on the 2005 National Electrical Code
by H. P. Richter, W. C. Schwan, F. P. Hartwell
Publisher: Park Publishing, Inc.
Pub. Date: May, 2005
ISBN-13: 978-0971977907

Roof Framing

Roof Framing
by Marshall Gross
Publisher: Craftsman Book Company
Pub. Date: July, 1984
ISBN-13: 978-0910460408




Wiring a House



Wiring a House
by Rex Cauldwell
Publisher: Taunton Press
Pub. Date: August, 2002
ISBN-13: 978-1561585274

Roofing, Flashing and Waterproofing

Roofing, Flashing and Waterproofing
by Fine Homebuilding Editors (Editor)
Publisher: Taunton Press
Pub. Date: October, 2005
ISBN-13: 978-1561587780




Roofing with Asphalt Shingles



Roofing with Asphalt Shingles
by Mike Guertin
Publisher: Taunton Press
Pub. Date: November, 2002
ISBN-13: 978-1561585311

Drywall

Drywall: Professional Techniques for Great Results
by Myron R. Ferguson
Publisher: Taunton Press
Pub. Date: April, 2002
ISBN-13: 978-1561585298




Tiling



Tiling: Planning, Layout and Installation
by Fine Homebuilding Editors (Editor)
Publisher: Taunton Press
Pub. Date: October, 2005
ISBN-13: 978-1561587889

Complete Drywall

Stanley Complete Drywall
by Ken Sidey (Editor)
Publisher: Stanley
Pub. Date: August, 2005
ISBN-13: 978-0696225499




Complete Tiling



Stanley Complete Tiling
by Ken Sidey (Editor)
Publisher: Stanley
Pub. Date: August, 2004
ISBN-13: 978-0696221132

Complete Wiring

Stanley Complete Wiring
by Ken Sidey (Editor)
Publisher: Stanley
Pub. Date: August, 2003
ISBN-13: 978-0696217302




Complete Trimwork



Stanley Complete Trimwork & Carpentry
by Larry Johnston (Editor)
Publisher: Stanley
Pub. Date: August, 2004
ISBN-13: 978-0696221149

Complete Decks

Stanley Complete Decks
by Larry Johnston (Editor)
Publisher: Stanley
Pub. Date: January, 2005
ISBN-13: 978-0696221163




Complete Patios



Stanley Complete Patios
by Ken Sidey (Editor)
Publisher: Stanley
Pub. Date: January, 2006
ISBN-13: 978-0696227370

Tile Your World: John Bridge's New Tile Setting Book

Tile Your World: John Bridge's New Tile Setting Book
by John P. Bridge
Publisher: Mistflower Press
Pub. Date: December, 2003
ISBN-13: 978-0974275437




Stone: Designing Kitchens, Baths and Interiors with Natural Stone



Stone: Designing Kitchens, Baths and Interiors with Natural Stone
by Heather E. Adams, Earl G. Adams
Publisher: Harry N. Abrams
Pub. Date: October, 2003
ISBN-13: 978-1584792901

The Complete Guide to Decks

The Complete Guide to Decks: A Step-by-Step Manual for Building Decks
by Editors of Creative Publishing
Publisher: Creative Publishing international
Pub. Date: June, 2005
ISBN-13: 978-1589232006



Ultimate Guide to Masonry & Concrete



Ultimate Guide to Masonry & Concrete: Design, Build, Maintain
by Editors of Creative Homeowner
Publisher: Creative Homeowner
Pub. Date: February, 2006
ISBN-13: 978-1580112987
